1T flake ice machine

Hotline:0757-23335676
Product description
Parameters

Commercial flake ice machine equipment with large capacity 10 ton
10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom


Flake ice machine parameters

 Model

 Output capacity

(Ton/day)

 Refrigerant

 Run Power

(Kw)

 Operating Weight

(Kg)

 Demention

(mm)

 XF-0.3T 0.3  R404 1.8 250 900*900*700
 XF-0.4T 0.4  R404 2.3 300 1200*900*700
 XF-0.5T 0.5  R404 2.4 380 1200*900*700
 XF-0.6T 0.6  R404 2.8 420 1200*900*700
 XF-0.8T 0.8  R404 3.5 500 1200*900*900
 XF-1.0T 1.0  R404 4.4 550 1200*900*900
 XF-1.2T 1.2  R404 5.5 600  1200*900*900
 XF-1.5T 1.5   R404 7.9 700 1300*1100*1000
 XF-2.0T 2.0   R404 8.7 850  1300*1100*1100
 XF-2.5T 2.5  R404 9.8 950 1300*1100*1200
 XF-3.0T 3.0  R404 11.5 1200 1700*1400*1300
 XF-4.0T 4.0  R404 18 1500 1800*1400*1400
 XF-5.0T 5.0  R404 22 1800 1800*1400*1400
 XF-6.0T 6.0  R404 25 2000 1800*1400*1500
 XF-8.0T 8.0  R404 31 2500 2750*1800*1900
 XF-10.0T 10.0  R404 35 2800 2750*1800*2000
 XF-12.0T 12  R404 42 3200 2750*1800*2100
 XF-15.0T 15  R404 52 4200 3200*2100*2300
 XF-20.0T 20  R404 67 5200 3500*2100*2500
 XF-25.0T 25  R404 84 5800 4300*2300*2300
 XF-30.0T 30  R404 101 6500 4500*2300*2500
 XF-40.0T 40  R404 135 7500 5100*2600*3000
 XF-50.0T 50  R404 169 9200 5100*2600*3200
 XF-60.0T 60  R404 200 11000 5600*2700*3500

Flake ice machine Features
1.Excellent performance
High efficiency. Under the set working conditions, the actual ice making output is 5%-10% more than that labeled on the machine.
2.High-precision evaporator
Evaporator adopts the advanced vertical lathe processing, no deformation and ice droing off completely.
3.Refrigeration system
The whole refrigeration system is clean, smooth, and no leakage at all welds; Long lifetime of the whole machine is up to 10 years.
4.PLC intelligent control.
Timing switch, remote control. Fault informtion is shown and recorded on the screen, and sent to the server automatically, to send Real-time Fault Alarm Information to Engineering Departments.
5.Ice skates
Ice skates with stainless steel 304, which is low-noisy, stable and durable.
6.High quality configuration
The world famous components ensure to long using time and stable operation.

10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom


10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom

10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom
10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom



Wide application
1. Fish, meat, vegetable, fruit keep fresh.
2. Concrete cooling.
3. Industrial usage
4. Supermaket, restaurant goods keep fresh.
5. Aquatic product keep cooling


10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom



Flake ice machine for fish market
1. Production of our flake ice machine is very economical with low consumption.
2. Wide interface area and fast refrigeration.
3. Effect on fish preservation of our flake ice machine is really excellent.
4. Commix thoroughly.
5. As the dry property, flake ice made by our flake ice machine is hard to stick during low temperature, so convinient for storage and transport.

10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom
10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom

Packaging & Shipping
1. Standard export standard.
2. A full set of ice machine includes:  the unit, cover,cooling tower, water pump, water pipes and water pipe.
3. The machine come into be used, the customer only need prepare power and water for the machine.
4. All required components for installing the machine will be provided.
5. Cold room is also available.



10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom


TIPS :

1. Product customization.

2. Payment term:  100% by T/T. 40% down payment for confirming the order, the balance is to paid off before loading.

3. Delivery: 45 working days after receipt of the deposit.

4. The price should be negotiated and accepted by both parties.

10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom

10 Ton Industrial Commercial Ice Flake Making Machine Price with Crusher and Coldroom

Now we (SNOWLAND) want to recruit agents and distributors sincerely from the global. We are welcomed and glad to have you in the same line with us. If you have strong passion for entrepreneurship and ambition,  believe our technology and skill, products and service, we (SNOWLAND) hope you become our strategic partners. And we (SNOWLAND) are devoted to provide the best products and service to the global clients with you.

Please contact us at anytime, we'll definately contact you immediately.


FAQ
1. Q: Is the ice machine with the refrigerant?
A: Yes, The machine come into be used, the customer only need prepare power and water for it.

2. Q:  Are the ice machine tested in your factory?
A: Yes, each ice machine must be strictly tested before its delivery.
